TypeORM: search in relationships (ft. NestJS)
🤔 Why?
Because I didn’t want to perform a full search once I brought all the records. Since SQL is really optimized for queries. For this case, I wanted to filter some records based on their relationship attributes.
I’ll use a simple test case.
💡 First, we need two TypeORM entities
For the most simple of cases, let’s suppose we have two classes. A Pet
and an Owner
. A Pet will belong to only one Owner. Both entities live in the same folder.
import { Column, Entity, JoinColumn, ManyToOne, PrimaryGeneratedColumn } from "typeorm";import { Owner } from "./owner";
@Entity()export class Pet { @PrimaryGeneratedColumn() id: number;
@Column({ name: "owner_id" }) ownerId: number;
@ManyToOne(() => Owner) @JoinColumn({ name: "owner_id" }) owner: Owner;}
And
import { Column, Entity, JoinColumn, OneToMany, PrimaryGeneratedColumn } from "typeorm";import { Pet } from "./pet";
@Entity()export class Owner { @PrimaryGeneratedColumn() id: number;
@Column({ name: "first_name" }) firstName: string;
@Column({ name: "last_name" }) lastName: string;
@OneToMany(() => Pet, () => Owner) @JoinColumn({ name: "owner_id" }) pets: Pet[];}
🔨 Creating the method for the controller
We will use NestJS. A simple NestJS controller seems like the following example.
@Controller("pets")export default class AppController { @Get() async search() { // TODO: Implement search }}
As you see here. The URL for the search will be /pets/search
🚛 Using Repositories
This is the method Typescript friendly. I prefer this since I’ll have type validation if I update any field in the future.
import { Controller, Get, Query } from "@nestjs/common";import { Pet } from "./entities/pet";import { FindManyOptions, FindOptionsWhere, Like, Repository } from "typeorm";import { InjectRepository } from "@nestjs/typeorm";
@Controller("pets")export default class AppController { constructor(@InjectRepository(Pet) private petRepository: Repository<Pet>) {}
@Get("/repository") async searchUsingRepository(@Query("search") search?: string) { // By default we load the relationship in the default options const options: FindManyOptions<Pet> = { relations: { owner: true } };
if (search?.length) { // if search request query param was sent. Create an array of words const searchFormattedText = search.trim().split(" "); const where: FindOptionsWhere<Pet>[] = [];
// Create OR WHERE queries by each word into first and last name for (const word of searchFormattedText) { where.push({ owner: { firstName: Like(`%${word}%`) } }); where.push({ owner: { lastName: Like(`%${word}%`) } }); }
// Adding those where to options options.where = where; }
const pets = await this.petRepository.find(options);
return { pets }; }}
It will produce the following query
SELECT `Pet`.`id` AS `Pet_id`, `Pet`.`owner_id` AS `Pet_owner_id`, `Pet__Pet_owner`.`id` AS `Pet__Pet_owner_id`, `Pet__Pet_owner`.`first_name` AS `Pet__Pet_owner_first_name`, `Pet__Pet_owner`.`last_name` AS `Pet__Pet_owner_last_name`FROM `pet` `Pet` INNER JOIN `owner` `Pet__Pet_owner` ON `Pet__Pet_owner`.`id` = `Pet`.`owner_id`WHERE ((`Pet__Pet_owner`.`first_name` LIKE ?) OR (`Pet__Pet_owner`.`last_name` LIKE ?))
🚛 Using Query Builder from repositories
This method is more close to SQL. Useful if you’re more comfortable with it.
import { Controller, Get, Query } from "@nestjs/common";import { Pet } from "./entities/pet";import { Brackets, SelectQueryBuilder, Like, Repository } from "typeorm";import { InjectRepository } from "@nestjs/typeorm";
@Controller("pets")export default class AppController { constructor(@InjectRepository(Pet) private petRepository: Repository<Pet>) {}
@Get("/querybuilder") async searchUsingQueryBuilder(@Query("search") search?: string) { // This is how we load relationships here let query = this.petRepository.createQueryBuilder("p").innerJoinAndSelect("p.owner", "o");
if (search?.length) { // By default we load relationship in the default options const searchFormattedText = search.trim().split(" ");
// With query builder we specify the AND or OR queries // Brackets is a way to group queries within a ( ) query = query.andWhere( new Brackets((queryPart: SelectQueryBuilder<Pet>) => { for (const word of searchFormattedText) { queryPart.orWhere("o.first_name like :firstName", { firstName: `%${word}%`, }); queryPart.orWhere("o.last_name like :lastName", { lastName: `%${word}%`, }); } }), ); }
const pets = await query.getMany();
return { pets }; }}
The query for the function above will result as
SELECT `p`.`id` AS `p_id`, `p`.`owner_id` AS `p_owner_id`, `o`.`id` AS `o_id`, `o`.`first_name` AS `o_first_name`, `o`.`last_name` AS `o_last_name`FROM `pet` `p` INNER JOIN `owner` `o` ON `o`.`id` = `p`.`owner_id`WHERE (`o`.`first_name` like ? OR `o`.`last_name` like ?)
⭐ Final result
This is the final controller. I’ll add a docker-compose file if you want to try it by yourself. Also, there is a /fake
method to create records if you want to test the search.
Remember, this is ONLY the main controller. Check my FULL demo on Github here
import { Controller, Get, Post, Query } from "@nestjs/common";import { Pet } from "./entities/pet";import { Brackets, FindManyOptions, FindOptionsWhere, InsertResult, Like, Repository, SelectQueryBuilder,} from "typeorm";import { InjectRepository } from "@nestjs/typeorm";import { Owner } from "./entities/owner";
@Controller("pets")export class AppController { constructor( @InjectRepository(Pet) private petRepository: Repository<Pet>, @InjectRepository(Owner) private ownerRepository: Repository<Owner>, ) {}
@Get("/repository") async searchUsingRepository(@Query("search") search?: string) { const options: FindManyOptions<Pet> = { relations: { owner: true } };
if (search?.length) { const searchFormattedText = search.trim().split(" "); const where: FindOptionsWhere<Pet>[] = [];
for (const word of searchFormattedText) { where.push({ owner: { firstName: Like(`%${word}%`) } }); where.push({ owner: { lastName: Like(`%${word}%`) } }); }
options.where = where; }
const pets = await this.petRepository.find(options);
return { pets }; }
@Get("/querybuilder") async searchUsingQueryBuilder(@Query("search") search?: string) { let query = this.petRepository.createQueryBuilder("p").innerJoinAndSelect("p.owner", "o");
if (search?.length) { const searchFormattedText = search.trim().split(" ");
query = query.andWhere( new Brackets((queryPart: SelectQueryBuilder<Pet>) => { for (const word of searchFormattedText) { queryPart.orWhere("o.first_name like :firstName", { firstName: `%${word}%`, }); queryPart.orWhere("o.last_name like :lastName", { lastName: `%${word}%`, }); } }), ); }
const pets = await query.getMany();
return { pets }; }
@Post("/fakes") async fakes() { const ownerPromises: Promise<InsertResult>[] = []; let ownerCount = await this.ownerRepository.count();
for (let i = ownerCount + 1; i <= ownerCount + 100; i++) { const owner = new Owner(); owner.firstName = `first_${i} name_${i}`; owner.lastName = `last_${i} name_${i}`; ownerPromises.push(this.ownerRepository.insert(owner)); }
await Promise.all(ownerPromises);
ownerCount = await this.ownerRepository.count();
const petPromises: Promise<InsertResult>[] = []; let petCount = await this.petRepository.count();
for (let j = petCount + 1; j <= petCount + 100; j++) { const pet = new Pet(); pet.ownerId = this.#randomInteger(1, ownerCount); petPromises.push(this.petRepository.insert(pet)); }
await Promise.all(petPromises);
petCount = await this.petRepository.count();
return { ownerCount, petCount }; }
#randomInteger(min: number, max: number) { min = Math.ceil(min); max = Math.floor(max); return Math.floor(Math.random() * (max - min) + min); }}
